REFURBISHED
Cisco
Cisco C9130AXI-B Wi-Fi 6 Internal Antenna Wireless Access Point
MPN: C9130AXI-B
Request Bulk Quote
Lifetime
Warranty
ISO 9001
Certified Testing
R2v3
Responsible Refurb
25+
Years
5K+
Customers
ISO
Certified
✓
Tested
Every WhaleyComm unit is professionally tested, reset to factory defaults, and certified by our in-house engineers — the same standard trusted by 5,000+ organisations across 25 years. Not a refurb marketplace. A certified lifecycle partner.
Tested to factory specification. Backed by 25 years of enterprise trust.
This professionally tested, refurbished Cisco Catalyst C9130AXI-B is a dual-band, dual-concurrent, enterprise-class Wi-Fi 6 (802.11ax) indoor wireless access point featuring internal antennas. Engineered for the B regulatory domain, the C9130AXI-B delivers up to 5.38 Gbps aggregate throughput across the 2.4 GHz and 5 GHz bands, making it a high-performance solution for demanding campus and enterprise environments. Each unit ships fully reset to factory defaults with a Certificate of Testing.The C9130AXI-B supports up to four concurrent Wi-Fi radios: a flexible 5 GHz radio operating as either a single 8x8 or dual 4x4 configuration, a 2.4 GHz 4x4 radio, and a dedicated Cisco RF ASIC for spectrum intelligence. OFDMA and MU-MIMO enable simultaneous multi-client communication in both uplink and downlink directions, reducing overhead and latency in high-density deployments. The access point features a 1x 5GBase-T Multigigabit Ethernet uplink (UPOE), a USB 2.0 management port, integrated Bluetooth Low Energy (BLE) 5 radio for IoT and location services, and 2048 MB DRAM / 1024 MB flash. Power is supplied via 802.3at (PoE+) or 802.3bt (Cisco UPOE). Security is enterprise-grade with support for WPA3 and Cisco Trust Anchor Technologies. Compatible with Cisco Catalyst 9800 Series Wireless Controllers, Cisco DNA Center, and Embedded Wireless Controller (EWC) mode.
WhaleyComm's refurbished C9130AXI-B delivers the same enterprise-grade Wi-Fi 6 performance as a new unit at a fraction of the cost — backed by our Lifetime Warranty, ISO 9001-certified testing process, and 25+ years serving 5,000+ enterprise customers. For teams modernizing high-density wireless infrastructure on a controlled budget, this unit is the proven path forward.
Technical Specifications
Part Number
C9130AXI-B
Wi-Fi Standard
802.11ax (Wi-Fi 6), backward compatible with 802.11a/b/g/n/ac
Frequency Bands
2.4 GHz and 5 GHz (dual-band, dual-concurrent)
Antenna Type
Internal; 4x4 MIMO (2.4 GHz), 8x8 MIMO / dual 4x4 MIMO (5 GHz, flexible)
Aggregate Throughput
Up to 5.38 Gbps
Radio Architecture
Up to 4 radios: 5 GHz flexible radio (8x8 or dual 4x4), 2.4 GHz (4x4), Cisco RF ASIC
Uplink Port
1x 1/2.5/5GBase-T Multigigabit Ethernet (UPOE) RJ-45
Management Port
1x RJ-45 management console; 1x USB 2.0
System Memory
2048 MB DRAM; 1024 MB Flash
Power Requirements
802.3at PoE+ (25.5W); 802.3bt / Cisco UPOE (30.5W); Cisco AIR-PWRINJ6=
Bluetooth
Integrated BLE 5 radio
Security
WPA2-Enterprise, WPA3; Cisco Trust Anchor Technologies
Operating Temperature
32°F to 122°F (0°C to 50°C)
Dimensions (C9130AXI)
8.9 x 8.9 x 1.88 in. (22.6 x 22.6 x 4.8 cm)
Weight
3.2 lb. (1.45 kg)
Regulatory Domain
B Domain (United States)
Controller Compatibility
Cisco Catalyst 9800 Series WLC, Cisco AireOS WLC, Embedded Wireless Controller (EWC), Cisco DNA Center
Operating System
Cisco IOS XE
Certifications
Wi-Fi 6 Certified; FCC; RoHS; CE
Ideal Use Cases
High-Density Enterprise Campus Deployments
The C9130AXI-B's 8x8 MU-MIMO, OFDMA, and up to 5.38 Gbps aggregate throughput make it purpose-built for lecture halls, open-plan offices, and conference centers where dozens to hundreds of clients connect simultaneously.
IoT-Heavy Environments
The integrated Cisco RF ASIC and BLE 5 radio enable simultaneous management of traditional Wi-Fi clients and low-bandwidth IoT devices, making this AP ideal for smart buildings, healthcare facilities, and manufacturing floors.
SD-Access and Intent-Based Network Fabric
Native support for Cisco Software-Defined Access (SD-Access) and Cisco DNA Center allows network teams to automate policy enforcement and gain real-time analytics across a unified wired and wireless fabric.
Wireless Controller Refresh or Scale-Out
Compatible with Cisco Catalyst 9800 Series Wireless Controllers and AireOS, the C9130AXI-B slots seamlessly into existing Cisco wireless infrastructures as a direct upgrade from older Aironet access points.
Budget-Conscious Wi-Fi 6 Migrations
Organizations ready to migrate to Wi-Fi 6 without the new-unit price premium can deploy refurbished C9130AXI-B units — same specs, same performance, significantly lower capital expenditure.
Education and Healthcare Networks
The access point's ability to support up to 1,024 simultaneous clients, combined with WPA3 security and Cisco CleanAir interference mitigation, makes it well-suited for high-density, compliance-sensitive environments.
What's Included
Cisco C9130AXI-B Wi-Fi 6 Internal Antenna Wireless Access Point
Ceiling/wall mounting bracket
Certificate of testing and factory reset
WhaleyComm Lifetime Warranty certificate
Lifetime Warranty — No Time Limits. No Questions.
Every WhaleyComm unit ships with a Lifetime Warranty. If it fails under normal operating conditions at any point, we replace it. We have stood behind our hardware for 25 years and 5,000+ customers — that is not a marketing line, it is our operating standard.
Compatibility Details
Review supported optics, cables, software, management protocols, and environment-specific compatibility guidance.
Wireless Controllers
✓
Cisco Catalyst 9800-CL, 9800-L, 9800-40, 9800-80 Series Wireless Controllers
✓
Cisco AireOS Wireless Controllers (requires AireOS released July 2021 or later)
✓
Embedded Wireless Controller (EWC) — no external controller required
Management Platforms
✓
Cisco DNA Center (intent-based networking and analytics)
✓
Cisco Prime Infrastructure
✓
Cisco IOS XE CLI
Power Accessories
✓
Cisco AIR-PWRINJ6= Power Injector (802.3at PoE+)
✓
Cisco AIR-PWRINJ5= Power Injector (802.3af only — limited mode)
✓
Any 802.3at PoE+ or 802.3bt/UPOE capable switch port
Mounting Accessories
✓
Cisco AIR-AP-BRACKET-1= (low-profile ceiling mount)
✓
Cisco AIR-AP-BRACKET-2= (universal mount)
✓
Cisco AIR-AP-BRACKET-3= (hard ceiling/wall mount)
For compatibility verification specific to your environment, contact our engineering team: +1 214 607-4800 or sales@whaleycomm.com
Shipping & Returns
Clear fulfilment, tracking, return, warranty, and support information for enterprise hardware orders.
Shipping
Orders typically ship within 1-2 business days after payment confirmation. Tracking details are shared once the order has been dispatched.
Returns
Eligible products can be returned according to WhaleyComm's return policy. For DOA, warranty, or product-related issues, contact the support team for replacement or resolution.
Frequently Asked Questions
Product-specific answers about compatibility, testing, warranty, fulfilment, and purchase confidence.
The C9130AXI-B is a Wi-Fi 6 (802.11ax) access point, backward compatible with 802.11a/b/g/n/ac. It delivers up to 5.38 Gbps of aggregate throughput across the 2.4 GHz and 5 GHz bands using OFDMA and 8x8 MU-MIMO on the 5 GHz radio.
The C9130AXI-B is powered via 802.3at PoE+ (25.5W) or 802.3bt/Cisco UPOE (30.5W) — no power adapter is included in the standard unit. A compatible PoE+ switch port or the Cisco AIR-PWRINJ6= power injector is required for operation. Full 8x8 radio capability on the 5 GHz band requires UPOE; PoE+ limits operation to 4x4 on 5 GHz with USB disabled.
The C9130AXI-B works with Cisco Catalyst 9800 Series Wireless Controllers, Cisco AireOS-based controllers, and supports Embedded Wireless Controller (EWC) mode for controller-less deployments. It is also fully manageable via Cisco DNA Center for intent-based networking.
Yes. Every WhaleyComm unit ships with a Lifetime Warranty. If it fails under normal operating conditions at any point, we replace it at no cost — no time limits, no questions asked.
Every unit goes through our ISO 9001-certified testing process: full power-on diagnostics, port-by-port functionality testing, firmware verification, factory reset, and final inspection. A Certificate of Testing ships with every unit.
